250 Amps Petrol Welding Generator , Model HPW-250D, Recoil Start

250 Amps Petrol Welding Generator , Model HPW-250D, Recoil Start

( 10 Reviews )

₹ 77960.24 (incl Of all taxes)

₹ 66068 + 18 % Gst + Delivery to pay

~~₹ 91992~~

15% off

In Stock

About This Product

DC Welding Output: 50 to 200 Amps
Electrode Dia.: 2.6mm to 4mm (E 7018)
*AC. Output VA: Inverter 1.2 KVA (Optional)
Starting System : Recoil Start
Fuel Consumption: Petrol 1 Ltr./Hr. Approx
Run time: 12 hr. Approx

Special Highlight:

World’s Most Portable, Professional & Low Cost Arc Welding Machine Suitable for High Class Welding Including Structural Welding Rods 7018 Size 4mm Electrode.

This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Category: GENERATORS

Easy Return & Refund

Quality Assurance

Trusted Delivery

After Sales Assistance

Buyer Protection

Maximum Output (Duty Cycle 60%): 200 Amps.
Welding Output at 100 % duty Cycle :175 Amps
Working Voltage: 20v to 32v
Open Circuit Voltage : 70 Volt (Maximum)
Current Regulation Amps : *75-200
Rectifying Mode : SCR, Phase Controlled 3-phase, Rectifying Bridge
Maximum Electrode diameter : 2.6 mm to 4.0 mm (E 7018)
Alternator Type :Multiphase, Brush less with Rear Earth Magnet Rotor

Engine

Model : HM170FB
Type : Single Cylinder Air-cooled; 4-stroke, OHV 25˚ Inclined
Maximum Power :7.5 HP
Bore x Stroke : 70x58
Displacement : ... Show More

Maximum Output (Duty Cycle 60%): 200 Amps.
Welding Output at 100 % duty Cycle :175 Amps
Working Voltage: 20v to 32v
Open Circuit Voltage : 70 Volt (Maximum)
Current Regulation Amps : *75-200
Rectifying Mode : SCR, Phase Controlled 3-phase, Rectifying Bridge
Maximum Electrode diameter : 2.6 mm to 4.0 mm (E 7018)
Alternator Type :Multiphase, Brush less with Rear Earth Magnet Rotor

Engine

Model : HM170FB
Type : Single Cylinder Air-cooled; 4-stroke, OHV 25˚ Inclined
Maximum Power :7.5 HP
Bore x Stroke : 70x58
Displacement : 223cc
Starting System : Recoil Start
Ignition System : TCI (Transistor Control Ignition)
Fuel : Standard Petrol
Fuel Tank Capacity :12 Liters
Fuel Consumption # Ltr./Hr. (at 60 % Duty Cycle) : 1.0Ltr./hr.
Continuous Operating Hour : 12 hr.
Lube. Oil Capacity : 600 ml.
Lubricating Oil Consumption : 2.5 gm./Hr.

Standard Accessories

Tool Kit : 1 Set
Welder Holder : 1 Set
Earthing Clamp with 3Mtr. Cable : 1 Set
Oil Funnel : 1 No
Owner’s Manual : 1 No

Panel & Other Features

Aux. AC Output 230 Volt - 50 Hz : Invertor 1200 VA – 220 Volt AC, 50 Hz (Optional)
Overload Protection (NFB) : Yes (Inverter)
Power Indicator : No
Ampere Meter : Yes
Engine Oil Protection : Yes (Electronic Oil Alert & Indicator)
Fuel Level Gauge: Yes

Size & Weight

Dimension LxWxH (mm) :600x450x530 mm
Dry Weight (Kgs.): 50 Kgs.

*For low welding current 50-75 Amps use “Sheet Metal Welding Attachment” (Optional at Extra Cost)

Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specification’s can change without any prior intimation

Show Less

HIMALAYAN POWER MACHINE MFG. CO.

Part of Khasra No. 51 and 52 Ka, Village Kuanwala, Haridwar Road, Dehradun,

Uttarakhand – 248001

Warranty

Warranty Summary	*1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier
Service Type	Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint
Covered in Warranty	*1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier
Not Covered in Warranty	NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
