225 Amps welding generator, Model- GE-W5500Ri
₹ 118588.82 (incl Of all taxes)
₹ 100499 + 18 % Gst + Delivery to pay
₹ 130000
In Stock
About This Product
- Welding Output Current (Duty Cycle60%) : 200Amps.
- Open Circuit Voltage (OCV): 65 Volt (Minimum)
- Electrode diameter : 2.6 mm to 4.0 mm
- Starting System : Recoil Start
- Fuel Consumption Ltr./Hr. : 1.0 Ltr./hr. (Approx)
- Continuous Operating Hour : 12 hr.
Special Highlights & Applications
- Most Portable & Low Cost but high Quality Arc Welding Machine Suitable for all types General Purpose Structural Welding, and High speed Welding Jobs, Including Pipe Welding Etc. up to 4 mm Electrode
In built AC 230 volt – 50 Hz, Pure Sine Wave 5 KVA Generator for AC Appliances and Power Tools / Power Machinery
This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.
Easy Return & Refund
Quality Assurance
Trusted Delivery
After Sales Assistance
Buyer Protection
- Maximum Welding Current : 225 Amps
- Rated Welding Output Current (Duty Cycle60%) : 200 Amps.
- WorkingVoltage : 20vto30v
- OpenCircuit Voltage (OCV) : 65 Volt (Minimum)
- Welding CurrentRegulation (Amps) : 75 – 225 AMPS
- RectifyingMode : SCR,PhaseControlled3-phase,Rectifying Bridge
- MaximumElectrodediameter : 2.6mmto 4.0mm
- DC Alternator Type : Multiphase, Brush less with Permanent Magnet Rotor
AC GENERATOR
- AC Alternator Type : Brushless with Rear Earth Magnet Rotor
- Invertor : 100 KHz, IGBT Based Digital Invertor – 5 Kw
- ... Show More
- Maximum Welding Current : 225 Amps
- Rated Welding Output Current (Duty Cycle60%) : 200 Amps.
- WorkingVoltage : 20vto30v
- OpenCircuit Voltage (OCV) : 65 Volt (Minimum)
- Welding CurrentRegulation (Amps) : 75 – 225 AMPS
- RectifyingMode : SCR,PhaseControlled3-phase,Rectifying Bridge
- MaximumElectrodediameter : 2.6mmto 4.0mm
- DC Alternator Type : Multiphase, Brush less with Permanent Magnet Rotor
AC GENERATOR
- AC Alternator Type : Brushless with Rear Earth Magnet Rotor
- Invertor : 100 KHz, IGBT Based Digital Invertor – 5 Kw
- Maximum Power (VA) : 5000VA
- Rated Power (VA) : 3500VA
- Rated Current : 15 Amps.
- Output Current : 13 Amps.
- AC. Output Voltage & Frequency : 225 Volts ± 10 Volts, Single Phase – 50 Hz
- Frequency (Adjustable) : 50to60Hz.
- Classof Insulation : F
Engine
- Model : HM172P
- Type : SingleCylinderAir-cooled;4-stroke,OHV25˚Inclined
- Maximum Power : 9 HP
- Bore x Stroke : 72x58 mm
- Displacement : 240cc
- Starting System : Recoil Start
- Ignition System : TCI(TransistorControl Ignition)
- Fuel : Standard Petrol
- Fuel Tank Capacity : 12 Liters
- Fuel Consumption # Ltr./Hr. : 1.0 Ltr./hr.
- Continuous Operating Hour : 12 hr. Aproxx.
- Lube. Oil Capacity : 600 ml.
- Lubricating Oil Consumption : 2.5 gm./Hr.
Standard Accessories
- AC Plug : 1Pec.
- Tool Kit : 1 Set
- Welder Holder With Cable : 1 Set
- Earthing Clamp with Cable : 1 Set
- Oil Funnel : 1 No.
- Owner’s Manual : 1 No.
- Costar Wheels : Optional
Panel & Other Standard Features
- A.C. Circuit Protector : Yes
- A C. Pilot Lamp : Yes
- Engine Oil Protection : Yes (Electronic Oil Alert & Indicator)
- Fuel Level Gauge: Yes
- A.C. Output Sockets : Yes (1 Nos.)
Size & Weight
- Dimension LxWxH (mm) : 600x450x530 mm
- Dry Weight (Kgs.):
Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specification’s can change without any prior intimation
