200 Amps, 5.5 KVA AC Welding Generator, HPW C7500i
₹ 128999.96 (incl Of all taxes)
₹ 109322 + 18 % Gst + Delivery to pay
₹ 135000
In Stock
About This Product
- *Max AC. Output VA : 5500
- *Rated AC. Output VA : 5000
- Electrode Dia.: 2.6 mm to 4.0 mm
- Starting System : Recoil Start
- Fuel Consumption: Petrol: 1.5 Ltr./hr.
- Run time : 15 Hrs.
Special Highlight:
- Most suitable for Low , Medium & High Current DC Welding of thin Sheets, Arc Welding (MMA) on MS Sheets / Parts.
- AC Generator 5.5 KVA , AC 230 V, 50 Hz Output for Running AC Appliances
This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.
Easy Return & Refund
Quality Assurance
Trusted Delivery
After Sales Assistance
Buyer Protection
- Maximum Output (Duty Cycle 60%) : 200 Amps.
- Working Voltazge : 20v to 30 v
- Open Circuit Voltage : 50 ± 5 Volts
- Current Regulation Amps : 50 ± 5 Volts
- Rectifying Mode : PWM Inverter (Buck)Technology
- Maximum Electrode diameter : 2.6 mm to 4.0 mm
Engine
- Model : HM172 Pi
- Type : OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
- Maximum Power (Duty Cycle 60%) : 9 HP @ 3600
- Bore x Stroke : 72x58 mm
- Displacement : 240cc
- Starting System : Recoil Start
- FuelShow More
- Maximum Output (Duty Cycle 60%) : 200 Amps.
- Working Voltazge : 20v to 30 v
- Open Circuit Voltage : 50 ± 5 Volts
- Current Regulation Amps : 50 ± 5 Volts
- Rectifying Mode : PWM Inverter (Buck)Technology
- Maximum Electrode diameter : 2.6 mm to 4.0 mm
Engine
- Model : HM172 Pi
- Type : OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
- Maximum Power (Duty Cycle 60%) : 9 HP @ 3600
- Bore x Stroke : 72x58 mm
- Displacement : 240cc
- Starting System : Recoil Start
- Fuel : Petrol
- Fuel Tank Capacity : Petrol - 21.0 Ltr.
- Fuel Consumption # Ltr./Hr : Petrol: 1.5 Ltr./hr.
- Continuous Operating Hour : 15 Hrs.
- Lube. Oil Capacity : 600ml
- Lubricating Oil Consumption : 2.5 gm./Hr.
- Sound level (Db) (from 1 meter) : <86Db
Standard Accessories
- AC Plug : 1Pec.
- Tool Kit : 1 Set
- Welder Holder : 1 Set
- Earthing Clamp with 3Mtr. Cable : 1 Set
- Oil Funnel : 1 No.
- Owner’s Manual : 1 No.
Panel & Other Standard Features
- Digital Display : Yes,Volt,Hz,Amp.Meter
- Oil Alert System : Yes
- Fuel Level Gauge : Yes
- Overload Protection (NFB) : Yes
- Costar Wheels & Handle Sets : No
Size & Weight
- Dry Weight (Kgs.) : 45kg
- Dimension LxWxH (mm) :
Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation
Show Less
The HPW C7500i 200 Amps 5.5 KVA AC Welding Generator has proven to be a reliable and powerful machine for my workshop needs great product hpm thnku
This 200 Amp output handles heavy-duty welding tasks with ease, producing stable and consistent arcs. I’ve used it for structural steel repairs and fabrication work, and the performance has been excellent. excellent product hpm thnku
HPW C7500i for field welding jobs,it has delivered impressive performance. 200 Amp welding capacity easily handles thicker materials, AC output remains steady throughout operation. power supply is sufficient to run additional tools
